FX23 Series
[FunctionMAX™] High Speed Transmission, 0.5mm pitch Board-to-Board Floating Connectors
- 0.5mm pitch
Stacking (Height : 8 - 30mm)/Right Angle - Contacts available : 20/40/60/80/100/120 for signal + 4 for power source
- Floating range : X direction : ±0.6mm , Y direction: ±0.6mm
- High speed transmission (16 Gbps)
- Hybrid power design (3A/pin×4 lines)
- Current capacity: Signal contact 0.5A/pin, power contact 3A/pin
- Pick & Place Mounting (suction tape attached as standard)
- Excellent mating performance due to the large guide post
