DF40 Series
0.4mm Pitch, 1.5 to 4.0mm Height, Board-to-Board and Board-to-FPC Connectors
- Space-saving: Depth 3.38mm
- 1.5-4.0mm stacking height variations
- Supports USB4 Gen.2 (10Gbps) transmission*
- Long effective mating length: 0.45mm
- Secure mating with clear tactile click
- Contact buckling prevention
- Wide variety of variations (with shield: DF40G series, with complete lock: DF40GL Series, for ADAS: DF40T Series.
- Abundant variations in the number of contacts from 10 to 120 contacts
- Secure self-alignment with guide ribs: 0.33mm
- Structure to prevent soldering by nickel barrier
- Highly durable connector for inspection for production line is also available
* Only H=1.5mm type is compatible with Type-C signal transmission.
